The F15 features all the benefits of a reliable Yamaha 4-stroke outboard in a compact, lightweight and portable package that rivals any 2-stroke. If you are looking for the ultimate in reliable, compact and efficient portable power for your boat, the F15 will deliver you many years of hassle-free performance.
Features:
- The powerful, new twin-cylinder SOHC design boasts the largest displacement in its class
- Maintenance is a breeze with easily accessible oil and fuel system components
- Convenient front-mounted controls facilitate smooth shifting, easy, shallow water drive and single action steering friction adjustment
- The carrying handle and brims are designed for easier carrying, mounting, and removing the outboard motor
- Yamaha’s unique YDC-30 aluminum alloy protects the engine’s exterior parts, while a zinc coating, high-quality stainless steel and 5-stage exterior coating offers long-lasting protection inside and out
Specifications:
- Engine Type: Four stroke, SOCH in-line 2 cylinders
- Displacement: 362 cc
- Bore and Stroke: 63 x 58.1 mm (2.48″ x 2.29″)
- Rpm Range: 5000-6000
- Compression Ratio: 9.3
- Induction System: SOHC
- Alternator Output: 12V/10A (6.5A @ 1000 rpm)
- Fuel Delivery: Carburetor (1)
- Starting: Rope or electric
- Ignition: CDI microcomputer
- Lubrication: Wet sump
- Degree of Trim/Tilt: 4 positions/71 deg.
- Exhaust: Through propeller hub
- Cooling: Water/thermostatic control
- Gear Shift: F/N/R
- Gear Ratio: 13/27 (2.08)
- Recommended Fuel: Regular unleaded
- Recommended Oil: Yamalube 4-M FC-W 10W-30 or 20W-40
- Oil Capacity: 1.6 L (1.7 qt)
- Shaft Length: 15″ or 20″
- Dry Weight: 50 kg (111 lbs)
- Tilt System: Manual or power tilt
- Standard Propeller: 3-blade aluminum cupped (9 1/4″ x 10″)
- Fuel line included
- Factory Warranty: 3 years. Warranty begins on date of purchase.
